Equipment in the EE Lab
Test Equipment
In addition to the standard lab equipment, the UTA EE lab offers the equipment listed below.
Electroscope
Fluke Handheld MultiPro 510A DMM
Fluke Y8100 AC/DC Current Probe
Up to 200 Amps.
HP 8591E Spectrum Analyzer
Inductor Decade Box
Keysight N9923A Network Analyzers
Levitation Device
Available to GTA's and Instructors only.
NI USRP - Software Defined Radio
Pluto Software Defined Radio
Resistor and Capacitor Decade Boxes
Rhode & Schwarz FSH6
Sencore LC Meter
Tektronix MDO 3102/3052 Mixed Domain Oscilloscope / Spectrum Analyzer
Model 3102 is 1GHz / 5GS/s. Model 3052 is 500MHz / 2.5GS/s
Van De Graaff Generator
Available to GTA's and Instructors only.
Variable Transformer 0-130V a.c. up to 5 amps output
Available to GTA's and Instructors only.
Solder Equipment
W.E.P. 858D Hot Air Reflow Station
Journey Magnifier
Metcal Soldering Station with solder removal gun
Excellent for removing headers.
Solder Paste
Weller Digital Soldering Iron WE1010
Weller Fume Extractor
Weller WES Soldering Station
X-Tronic 4000 Hot Air Reflow Station
Tools and Equipment
Bantam Tools PCB Milling Machine
Maximum board size is 4" x 5". Double sided boards must be though hole plated. See Lab staff before making a double sided PCB.
LPKF PCB Milling Machine
Double sided boards must be though hole plated. See Lab staff before making a double sided PCB.
LPKF Through Hole Copper Plating Machine
PolyPrinter 3D Printer
Prints ABS. See Lab Staff for NinjaFlex Extruder.
Table Saw
Radial Saw
Drill Press
Portable Drill
Disk Sander
Dremil Kit
Needle Files
Tool Set
Scroll Saw
Clamps
LiPo Charger
Brad Nailer
Tap and Die
Heat Gun
Hole Saw Kit
Staple Gun
Elec, Stapler
Air Compressor
Hot Glue Gun
Digital Calipers
Angle Finder
IR Thermometer
Label Maker
RG-58 Tool Box
RG-6 Tool Box
Heat Shrink
Standard Sockets
Screwdriver set
Drill Bit set
Grabber / Magnet
Gap gauge
Inspection Tools
Safety
Face Shield
Gloves
Goggles
Respirator
Medical Masks
First Aid Kit
Laser Safety Glasses
Development Boards
Arduino Uno R3
TI MSP-430
TI-MSP-432
PIC Dev. Board
NI MyDAQ
Raspberry Pi 3
Boost CC2564
Boost - Audio
NI MyGrid
Rpi BB Adapter
Rpi Sensor Sheild
PicKit 3
FTDI Cable
TIVA Launchpad
Arduino Nano
Arduino Wifi 1010
Sensors
Elegoo Sensor Kit
3.7 V Motor
Photo-Resistor
Hall Effect Sensor
LCD Display
LM60 Temp Sensor
NEMA 17 Stepper
PIR Sensor
PIXY 2 Camera
TB6612 Motor Driver
Real Time Clock
Stepper Motor
Ultrasonic Sensor
X-Bee Radio
X-Bee Shield
X-Bee Programmer
Accelerometer
TI Sensor Tag
OLED Display
Buzzer (AC)
Buzzer (DC)
5 V Relay
DC to DC converter
IR LED RX/TX
Magnetic Swipe
RFID Kit
Rotary Encoders
SD Card Reader
Soil Moisture
Solar Panel
Wifi Board
Cables, Connectors and Adapters
Banana to SMD
BNC to SMD
BNC to Banana
Male DC Adapter
FTDI Cable
1 x 40 Male Headers
Female Headers
Jumper Wires
HDMI to VGA Adapter
JST Connectors
Assorted Terminal Blocks
Components and Misc.
Coin Cell Battery
Heat Sink Compound
Heat sinks
SD Cards
Double sided tape
Super Glue
NH241 EE/CSE Makerspace Equipment
Formech 450DT - Form molding
Formlabs 2 - 3D Resin printer
Manncorp RW1210 - SMD Placement machine
Shapeoko - CNC Mill
Thunder Laser - Laser cutting
Tormach PCNC 440
Ultimaker S5 3D Printer
